0.5KW Hot Air Circulation Oven / PCB Drying Oven With Leakage Protection

0.5KW Hot Air Circulation Oven / PCB Drying Oven With Leakage Protection

  • 0.5KW Hot Air Circulation Oven / PCB Drying Oven With Leakage Protection
0.5KW Hot Air Circulation Oven / PCB Drying Oven With Leakage Protection
Product Details:
Place of Origin: China
Brand Name: LONGYUE
Certification: ISO9001, CE
Model Number: LVO-0B(6020)
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: wooden case
Delivery Time: 7-15 working days
Payment Terms: T/T
Supply Ability: 100 set / month
Contact Now
Detailed Product Description
Power Supplly: AC 220V, 50Hz Power Rating: 0.5KW
Temperature Range(℃): RT+10~200℃ Temperature Fluctuation: ±1℃
Display Resolution: 0.1℃ Vacuum Degree: <133 Pa
Chamber Size (W×D×H)cm: 30×30×28 Exterior Size (W×D×H)cm: 58×57×45
Package Size (W×D×H)cm: 70×64×60
High Light:

vacuum drying cabinet

,

pharmaceutical drying oven

Hot Air Circulating Oven PCB Drying Oven LVO Vacuum Drying Oven



Apply to the drying, braking, wax melting and sterilization of the articles in industrial and mining enterprises, colleges and universities, scientific research and medical units, labs, etc.



Features

★ Microprocessor controller with LCD display, more accurate and reliable.

★ Polished stainless steel chamber,durable and easy to clean.

★ Tempered, bullet-proof double glass door ensure the safety of operator and clear observation of the chamber.

★ Door tightness can be adjusted,silicon sealing. To keep vacuum states in the chamber, can fill working chamber with inert gas (inflation pressure≦ 0.1 MPa).

★ Storage, heating, testing and drying can be performed in the environment without oxygen or in an inert atmosphere. It will not cause oxidation.

★ Equipped with leakage protection.



Options:

1. Programable temperature controller

2. Built-in Printer

3. RS485 Connector

4. Inert gas inlet valve

5. Small vacuum pump (6020, 6050)

6. Large vacuum pump (6090, 6210)



Specifications:

Model LVO-1B(6050) LVO-0B(6020) LVO-6090 LVO-6210 LVO-6933
Power Supplly AC 220V, 50Hz
Power Rating 1.4KW 0.5KW 1.6KW 2.2KW 5.5KW
Temperature Range(℃) RT+10~250 RT+10~200℃
Temperature Fluctuation ±1℃
Display Resolution 0.1℃
Vacuum Degree <133 Pa
Chamber Size (W×D×H)cm 42×35×37 30×30×28 45×45×45 56×60×64 75.5×116×115
Exterior Size (W×D×H)cm 71×59×53 58×57×45 61×66×145 72×82×175 93×130×182
Package Size (W×D×H)cm 82×70×69 70×64×60 78×76×163 89×92×193 120×145×200
Net/Gross(kg) 75/106 35/50 90/145 145/195 550×600
